Cosen SH-500M Semi-Automatic Horizontal Scissor Style Mitering Band Saw

Cosen SH-500M

Standard Features

  • Blade Length: 163 in
  • Blade Speed: 60Hz: 75, 114, 164, 246 FPM
  • Cut Method: Horizontal
  • Motor: 3 HP
  • Table Height: 32.6 in
  • Ship Wt: 1992 lbs.

Cutting Capacity

Cutting Angle Stock Shape Stock Size
Rectangular Stock 11" x 19.7"
Rectangular Stock 13"
45° Rectangular Stock 11" x 9.4"
Rectangular Stock 11.8"
60° Rectangular Stock 11" x 8.6"
Rectangular Stock 8.6"
Mouseover to zoom
Cosen SH-500MImage unavailableImage unavailableImage unavailableImage unavailable
Downloads
Item on backorder
$14,895.00

Temporarily Out Of Stock.
Residential    Commercial
No    Yes
This item requires a fork-lift for delivery.

Cosen SH-500M Description and Features

Application

  • Cosen provides a full range of semi-automatic band saws in a wide variety of cutting capacities. These saws exceed many of the standard requirements that operators look for in a band saw machine. With its rigid construction and superior features, Cosen's SH-500M fits into that category.

Features

  • Swivel saw head allows miter cutting from 0 degrees to 60 degrees
  • Hydraulic cylinder plus precision ground hinge support
  • Hardened worm gear for durability
  • Hard-stops at , 45, and 60 degrees for quick angle set up
  • Blade drive equipped with variable pulley system
  • Adjustable flood coolant system
  • Motor driven, synchronized wire blade brush
  • Carbide blade guides and bearing provides additional blade support
  • Rigid cast-iron guide arms
  • Cast-iron hydraulic vise
  • Adjustable down feed control
  • Adjustable material stop
  • Saw head automatically raises after each cut

Benefits

  • This heavy duty band saw offers precision, efficiency in operation, lower cost per cut, and durability in a demanding production environment
