High Performance Fabrication Saw - 9" Geared Drive, One-Way Swivel Band Saw

Trajan 270/270SV

Standard Features

  • Blade Guide: Carbide
  • Blade Length: 97 x 1
  • Blade Speed: 60HZ 128-276
  • Coolant Pump: Standard
  • Cut Method: Horizontal
  • Feed System: Manual
  • Laser Alignment: No
  • Miter Cut: No
  • Motor: 1.5HP 1Ø
  • Swivel Method: Head
  • Table Height: 0
  • Voltage: 220V
  • Ship Wt: 528 lbs.

Cutting Capacity

Cutting Angle Stock Shape Stock Size
-60° Bar Stock 3 1/2"
Rectangular Stock 3 7/8" X 3 1/2"
Square Stock 3 1/2" X 3 1/2"
Bar Stock 8 3/4"
Rectangular Stock 9 3/8" X 6 1/4"
Square Stock 7 7/8" X 7 7/8"
45° Bar Stock 6 1/4"
Rectangular Stock 6 1/8" X 4 1/2"
Square Stock 5 1/2" X 5 1/2"
Mouseover to zoom
Trajan 270 High Performance Fabrication SawTrajan 270 Fabrication Saw Vector ControlsTrajan 270 Fabrication Saw Blade BrushTrajan 270 Fabrication Saw Hydraulic Feed ControlTrajan 270 Fabrication Saw Blade tension Trajan 270 Fabrication Saw Cast Vise Bed
Item on backorder
$3,200.00

Temporarily Out Of Stock.
Residential    Commercial
No    Yes
This item requires a fork-lift for delivery.
This item requires 2 additional days for Make Ready Service prior to being shipped.

Trajan 270/270SV Description and Features

High Performance Fabrication Saw - 9" Geared Drive, One-Way Swivel Band Saw

Sawblade.com offers band saws fine-tuned to operator’s needs. The Trajan 270 is no exception. Its impressive array of standard features make it well suited to a wide array of shops. If your shop prioritizes precision cutting, band saw blade protection, and quick clean up, the Trajan 270 may be ideal for your shop.

Precise control
The adjustable blade guide helps to ensure that the Trajan 270 band saw will make the precise cut that the operator sets. The blade tension indicator helps operators to get the exact cut they require for delicate applications. Adjustable hydraulic downfeed controls also ensure that the saw cuts exactly as the operator intended.

Protects blade
The Trajan 270, like all Trajan band saws, is engineered to protect the band saw blade it’s using. Years of experience in the band saw industry has taught us what to prioritize in saw design. Many of the factors that make Trajan cutting machines to accurate also helps protect the band saw blade: the less vibration, the less wear and tear the blade has to take.

Quick clean up
Built with operator convenience in mind, the Trajan 270 band saw has a coolant pan designed to collect chips and coolant while the saw makes a cut. This feature makes for quick clean up between jobs. The chip brush also helps to sweep debris away from the cutting surface, which contributes to our effort to reduce blade damage.

High Performance Fabrication Saw – 9" Geared Drive, One-Way Swivel Band Saw

  • Cutting angle from 0 degree to 60 degree
  • Adjustable blade guide for high precision and long blade life
  • Stand jointed with coolant pan for collecting chips and coolant
  • Coolant system for wet cutting
  • With bi-metal blade, chip brush and length stop set
  • Blade tension indicator
  • Fully adjustable hydraulic downfeed handles the rate of descent for optional selection
  • Variable blade speed

Efficient and powerful, the Trajan 270/270SV band saw performs successfully in professional environments. It has an adjustable blade guide for high precision, which also helps prolong the band saw blade’s life. With a blade tension indicator and fully adjustable hydraulic down feed, you can make accurate cuts. Choose the Trajan 270/270SV band saw for your professional fabrication workloads.
